Blackberry tidak terlepas dari
permasalahan, salah satunya adalah kegagalan blackberry untuk hidup
kembali dengan indikasi terdapat layar putih dengan pesan kesalahan,
layar gelap hanya LED saja yang menyala atau bahkan hanya layar gelap
belaka (mati total atau sering disebut matot). Hal ini dapat diakibatkan
oleh banyak faktor. Secara garis besar penyebab matinya Blackberry
dapat dibagi menjadi 2 faktor yaitu:
- Kerusakan Hardware
- Kerusakan Software
Artikel ini mencoba mendiagnosis permasalahan apakah diakibatkan oleh
permasalahan hardware ataupun permasalahan software. Ada beberapa usaha
yang dapat dilakukan untuk mengatasi permasalahan ini yaitu copot
battery, tukar battery.
Copot Battery
Usaha pertama yang perlu dilakukan adalah dengan melakukan “Battery
Pull” atau copot battery. Hal ini dilakukan dengan cara melepas baterai
dan menunggu sekitar lebih kurang 3 menit sebelum memasang kembali
battery. Apabila tidak berhasil, coba lepas SIM Card dan Media Card
sebelum memasang kembali battery. Apabila blackberry masih tidak dapat
menyala, coba lakukan tukar battery atau Recharge battery yang caranya
akan dijelaskan berikut ini.
Tukar Battery
Usaha tukar battery bertujuan untuk memastikan bahwa permasalahan bukan
diakibatkan oleh battery, hal yang dapat dilakukan adalah dengan mencoba
memasang baterai yang “good” dan “fully recharge” ke blackberry yang
bermasalah. Apabila blackberry dapat menyala, ganti atau charge ulang
battery menggunakan cara berikut ini. Apabila tidak berhasil, artinya
permasalahan bukan disebabkan oleh battery, coba dengan me-”reload” OS.
Recharge Battery
Usaha ini mencoba melakukan charging pada battery yang sudah habis total.
- Cabut Baterai, SIM Card, Media Card, biarkan terbuka
- Jalankan Desktop Manager
- Sambungkan Blackberry dengan PC menggunakan kabel USB
- Tunggu sampai muncul gambar battery disilang
- Pasang battery tanpa melepas sambungan blackberry dengan PC
- Tunggu sampai Blackberry menyala, biarkan charge sampai beberapa garis battery
- Cabut koneksi, segera charge dengan charger
Masuk ke Safe Mode
Apabila masalah terjadi setelah instalasi aplikasi/themes dan setelah
reboot tidak dapat masuk ke home, coba masuk ke safe mode dan hapus
aplikasi/themes pada modus safe mode.
- Lepas dan pasang kembali baterai
- Ketika Lampu LED mati, tekan dan tahan tombol Escape sampai muncul kotak dialog
- Jawab OK
Untuk kembali ke modus normal dengan cara lepas batterai dan pasang kembali baterai.
Reload Sistem Operasi
Langkah pertama adalah mencoba me-load sistem operasi Blackberry menggunakan bantuan command prompt (lihat
Repair Nuked Blackberry).
Install Desktop Manager pada PC, kemudian install OS menggunakan OS
“bawaan” yang biasanya disertakan di dalam CD yang terdapat di dalam
kardus Blackberry. Pastikan OS lain yang sudah diinstall di dalam PC
dihapus terlebih dahulu.
Delete file Vendor.xml yang terdapat di dalam folder “Program Files/Common Files/Research in Motion/AppLoader”.
Pastikan Desktop Manager tidak “Running” di dalam Windows, apabila
Desktop Manager “Running”, Matikan autostart dan restart Windows.
Kemudian ikuti langkah langkah di bawah ini:
- Jalankan Command Prompt (Ketik Alt+R kemudian ketik cmd + Enter)
- Ketikkan pada Command Prompt
CD \ (Tekan Enter)
CD PROGRA~1 (Tekan Enter)
CD COMMON~1 (Tekan Enter)
CD RESEAR~1 (Tekan Enter)
CD APPLOA~1 (Tekan Enter)
LOADER /NOJVM (Tekan Enter)
- Tunggu sampai selesai
- Restore Backup anda dengan Desktop Manager apabila proses loading firmware selesai
Apabila cara ini masih belum berhasil, kemungkinan besar permasalahan Blackberry disebabkan oleh kerusakan Hardware.
LED Error Code
Kode kedipan lampu LED pada saat awal loading blackberry menunjukkan
suatu nilai biner yang menginformasikan pesan dari bootROM. Kode ini
ditampilkan dalam bentuk kedipan lampu led berwarna merah,
biner 1 ditunjukkan dengan nyala kedip (lampu merah) sedangkan biner 0
ditunjukkan dengan tidak nyalanya led (off). Apabila led menyala secara
kontinyu, ini merupakan pesan sedang melakukan security wipe, apabila
led menyala kontinyu tidak pada saat melakukan security wipe, ini
mengindikasikan adanya kerusakan hardware.
- 1 (desimal = 1) Bukan problem, kode ini adalah normal saat restart
- 11 (desimal = 3) Tidak ada sistem operasi di dalam blackberry, lakukan reload sistem operasi (pakai jurus /nojvm)
- 101 (desimal = 5) Bad OS CRC
- 111 (desimal = 7) Missing OS CRC
- 1011 (desimal = 11) Missing OS Trailer
- 1101 (desimal = 13)OS Not Signed, coba loading OS kembali
- 1111 (desimal = 15) OS Signature Invalid, coba loading kembali OS
dan biarkan mati tanpa baterai selama hampir 30 menit, kemudian coba
hidupkan kembali. Apabila tetap muncul pesak kesalahan, coba lakukan
penggantian flash.
- 10101 (desimal = 21) Unknown Flash Manufacturer, coba lakukan penggantian flash
- 10111 (desimal = 23) Flash Initialization Problem, coba lakukan penggantian flash
- 11011 (desimal = 27) Flash Erase Failure ,coba lakukan penggantian flash
- 11101 (desimal = 29) Flash Operation Out Of Range
- 11111 (desimal = 31) Bad BootROM CRC, coba lakukan penggantian flash
- 101011 (desimal = 43) USB Driver Error
- 101101 (desimal = 45) No BootROM CRC
- 101111 (desimal = 47) Flash Write Failure, coba lakukan penggantian flash
- 110101 (desimal = 53) Invalid Memory Configuration Table
- 110111 (desimal = 55) Password Not Initiated
- 111011 (desimal = 59) RAM Initialization Problem, coba lakukan penggantian flash
- 111101 (desimal = 61) Cache No Pages Free
- 111111 (desimal = 63) Cache Invalid Page Type
- 1010101 (desimal = 85) Random Number Failure
- 1010111 (desimal = 87) OSStore Failure
- 1011011 (desimal = 91) Security Init Failure
- 1011101 (desimal = 93) NAND failure
- 1011111 (desimal = 95) General Assert Failure
- 1101011 (desimal = 107) GPIO failure
- 1101101 (desimal = 109) Runtime library failure
- 1101111 (desimal = 111) Exception: undefined isntruction
- 1110101 (desimal = 117) Exception: SWI
- 1110111 (desimal = 119) Exception: Prefetch Abort
- 1111011 (desimal = 123) Exception: Data Abort
- 1111101 (desimal = 125) Exception: Reserved
- 1111111 (desimal = 127) Exception: IRQ
- 10101011 (desimal = 171) Exception: FIQ
JVM Error Code
- 101 Internal JVM error.
- 102 Invalid code in file system. The .cod files in the handheld
have been checked for modification and it has been determined that there
is a problem with one or more .cod files.
- 103 The starting address for the boot .cod file cannot be found.
This might mean that a boot .cod file has not been installed on the
handheld, or that its format is invalid or corrupt.
- 104 An uncaught Java exception was thrown in the Java code and
diagnosed by the JVM. Execution can be continued or the handheld can be
attached to a debugger on a desktop through a serial or USB cable. The
event log should contain the traceback of the thrown exception.
- 105 An OS file system API returned an error status for a certain
operation. This can indicate a corrupt file system or an error in the
JVM.
- 106 An error has been detected in the graphics system of the handheld.
- 107 Internal JVM error.
- 108 Internal JVM error.
- 109 Internal OS error.
- 110 Non-idle event downtime error. A problem has been detected
in the accumulation of JVM down time that represents how long the JVM
has been idle. This indicates an error in either the OS code or the JVM
code.
- 200 Application manager threw an uncaught exception. The
application manager event thread threw an uncaught exception and so
cannot continue running.
- 201 Initialization of the cryptographic system failed and the handheld cannot continue to operate.
- 202 An attack on the key store has been detected, and the handheld cannot continue to operate.
- 203 The application manager console process, usually the Home screen ribbon, has failed, like due to an uncaught exception.
- 501 Internal error.
- 502 All processes exited. The last Java process has terminated, and there is nothing left to execute.
- 503 Internal error.
- 504 Internal error.
- 505 Internal error.
- 506 An uncaught Java exception was thrown in the initial VM Java
thread thus killing the only live thread in the system. The event log
contains the traceback for the exception.
- 507 A dependency on a .cod file could not be satisfied due to a
missing .cod file. Load the missing .cod file onto the handheld.
- 508 Invalid object. A problem has been detected with a debugger command to the VM.
- 516 Error occurred during garbage collection, which might indicate a corrupted file system.
- 510 All threads are waiting on objects, which results in a
deadlock. The system cannot recover from this state since no thread can
release a lock.
- 511 A problem has occurred during debugging.
- 515 The reachable objects form a group that cannot be
represented properly by the VM because there are too many objects or the
total size of the objects is too large.
- 516 When committing a persistent object, the VM found that the
persistent store id counter has reached its limit. The object was not
committed.
- 517 An inconsistency has been detected in the VM persistent object store.
- 518 Internal error.
- 519 Internal error.
- 520 Internal error.
- 521 Indicates that Object.wait() has been executed by a thread
that holds a lock on another object; occurs only in simulator if the
JvmDebugWaits application switch.
- 522 A thread has acquired two locks on objects in an order that
doesn’t match the order that previous locks for the two types were
acquired, which indicates a future potential deadlock situation;
reported only in the simulator when the JvmDebugLocks application switch
is set.
- 523 A critical Java process has died and the device cannot continue to operate normally.
- 524 An object has been marked as recovered by the Low Memory
Manager but it was not freed during a garbage collection. This is only
checked in the simulator under the control of the JvmDebugLMM
application switch.
- 525 Bad persistent object. An auto-commit operation during a
garbage collection has detected a non-persistent object reachable from
the persistent store root. The type of the object has been output into
the event log.
- 526 The class definition for java.lang.Object cannot be found.
- 527 The class definition for java.lang.String cannot be found.
- 528 The file system is corrupted. Data on the handheld is unrecoverable.
- 529 The file system is corrupted. An attempt is going to be made to recover data, but some data might be lost.
- 530 Internal JVM error.
- 531 Flash memory has been exhausted.
- 532 A JVM assertion has been violated. This error can occur only in the simulator, not on an actual handheld.
